DOOSAN DX140LC-5 Medium Excavator

DOOSAN DX140LC-5 Medium Excavator

Operating weight 14400 kg
Engine Power 85.9kW/2000rpm
Send Inquiry

Advantages

    no features

Machine Styling

- New modern distinctive look



Emission Regulation Compliance

- Compliant: Stage IV
- Perkins engine: 1204F
- After treatment: EGR, SCR & DOC, DPF-free



Comfort & Controllability

- Greater Power & Performance
- Two-Way Pedal & Joystick improvements
- Straight travel pedal
- TMS Factory-installed



Fuel Efficiency

- Fuel efficiency improved up to 10%
- SPC (Smart Power Control)
- Auto Idle, shut-off & new fuel consumption menus



Components & Maintenance

- All front bushings ‘Enhanced Macro-surface’
- New anti-slip & new grip for front door

DX140LC-5

Specifications

Operating weight

14400 kg

Engine

Perkins 1204F

Engine power

85.9kW(117PS, 115HP) @2000rpm (SAE J1995)

Main pumps max flow

2 x 114/m

Number of cylinders

4

Travel speed

5.0/3.0 km/h

Maximum traction

12.6 Ton / 122 kN

Buckets

0.24 – 0.76 m³

Sound level (internal / external)

70 dB(A) - 99 dB(A)

Overall width

2590 mm

Overall height (Std Front)

3180 mm

Overall length (Std Front)

7640 mm

Tail swing radius

2205 mm

Bucket digging force

11 t

Arm digging force (Std Front)

6 t

Max. digging reach (Std Front)

8665 mm

Max. digging depth (Std Front)

6135 mm

Max. digging height (Std Front)

8745 mm
