Cat Track Asphalt Pavers AP255E

Cat Track Asphalt Pavers AP255E

Permalink :http://usa-product.global-ce.com/paver/cat/ruxt.html

Last Updated : 2018-03-23
Paving Speed 33.0 m/min
Max. Paving Thickness
Send Inquiry

Overview

With a single operator, the AP255E meets all requirements for small and medium sized jobsites. Easy, simplified driving - with controls which give precise, immediate response.  The AP255E is a compact, extremely versatile paver finisher, ideal for small jobsites in urban centers. For sidewalks, cycle paths, playgrounds, trench back filling and all maintenance and repair work, where it shows its notable qualities and features. This paver is designed to operate in limited spaces, thanks to its compactness and exceptional maneuverability.

Weights

Units:

Maximum Operating Weight9921.0 lb | 4500.0 kg
Operating Weight - With Screed9921.0 lb | 4500.0 kg

Operating Specifications

Standard Paving Width1400 mm - 2600 mm (4.6 - 8.5 ft) | 1400 mm - 2600 mm (4.6 - 8.5 ft)
Paving Width Minimum0.5 ft | 150.0 mm
Paving Width Maximum11.08 ft | 3400.0 mm
Hopper Capacity109.0 ft³ | 3.1 m³
Inside Turn Radius2.3 ft | 0.7 m
Maximum Paving Speed - With Vibratory Screed108.0 ft/min | 33.0 m/min
Maximum Travel Speed2.0 mile/h | 3.2 km/h
Truck Dump Height23.0 in | 0.58 mm
Truck Entry Width9.8 ft | 3.0 m

Engine

Gross Power46.0 HP | 34.1 kW
Displacement135.0 in³ | 2.21 l
Engine ModelCat C2.2 | Cat C2.2

Dimensions

Track Contact Length4.6 ft | 1.38 m
Overall Height8.3 ft | 2.5 mm
Inside Turn Radius2.3 ft | 700.0 mm
Length - With Push Roller and Largest Screed13.8 ft | 4.2 m
Length - With Push Roller and Screed13.8 ft | 4.2 m
Maximum Height8.3 ft | 2.5 m
Tractor Operating Width9.83 ft | 3.0 m
Transport Height5.75 ft | 1.74 m
Transport Width - Hoppers Raised - Screed End Gates Attached5.25 ft | 1.6 m

Service Refill Capacities

Fuel Tank Capacity17.0 gal (US) | 65.0 l
Hydraulic Oil Tank19.28 gal (US) | 73.0 l
Cooling System4.49 gal (US) | 17.0 l

Drive System

Maximum Paving Speed108.27 ft/min | 33.0 m/min

Hopper

Hopper Capacity109.48 ft³ | 3.1 m³
